4 Reasons to Compute Importance Using Relative Weights Rather than Shapley Regression

Relative importance analysis table

Shapley regression is a popular method for estimating the importance of predictor variables in linear regression. This method can deal with highly correlated predictor variables that are frequently encountered in real-world data. Shapley regression has been gaining popularity in recent years and has been (re-)invented multiple times1Lipovetsky, S. and Conklin, M. (2001). Analysis of regression in game theory approach. Appl. Stochastic Models Bus. Ind., 17: 319–330.2Lindeman, R.H., Merenda, P.F. and Gold, R.Z. (1980). Introduction to Bivariate and Multivariate Analysis, Scott, Foresman, Glenview IL.3Budescu, D.V. (1993). Dominance analysis: a new approach to the problem of relative importance in multiple regression. Psychol Bull 114:542-551. under various names such as dominance analysis or LMG. In this blog post, I explain why a newer method, relative weights4Johnson, J.W. (2000). A heuristic method for estimating the relative weight of predictor variables in multiple regression. Multivariate behavioral research 35, 1-19., should be used instead of Shapley regression.






Both methods give essentially equivalent results

The table below shows a typical example of the results from Shapley versus Relative Weights. The correlation between the two sets of scores is greater than 0.99. This is the norm, rather than a fluke5LeBreton, J.M., Ployhart, R.E. and Ladd, R.T. (2004). A Monte Carlo Comparison of Relative Importance Methodologies. Organizational Research Methods 7, 258 – 282.6Grömping, U. (2015). Variable importance in regression models, WIREs Comput Stat 7, 137-152.. It is not obvious from the maths how the two metrics are so similar, but they are. In fact, for models with two predictors, the two metrics have been proven to be identical7Thomas, D.R., Zumbo B.D., Kwan E., Schweitzer L. (2014). On Johnson’s (2000) Relative Weights Method for Assessing Variable Importance: A Reanalysis. Multivariate behavioral research 49, 329-338..

 ShapleyRelative Importance Analysis
Fun.035.036
Worth what you pay for.036.037
Innovative.034.034
Good customer service.029.030
Stylish.015.013
Easy-to-use.045.046
High quality.051.051
High performance.032.031
Low prices.002.002

For a more thorough analysis of the differences between Shapley and Relative Importance Analysis, please see this blog post.






1. Relative Weights are much faster to compute

The main problem with Shapley regression is that the computational resources required to run an analysis grows exponentially with the number of predictor variables. Shapley has become accessible in recent years due to the rapid increase in computing power, allowing models with less than 15 variables to be computed within seconds. However, with each additional variable, the time required more than doubles. A model with 30 variables would take days to run on a decent desktop computer. While the time required to run Relative Importance Analysis also increases with the number of predictor variables, it does not do so exponentially. Consequently, a 30 variable model will run almost instantly on a modern computer.

The difference in computational time merits our concern. A model that takes hours or days to run only gets run once, or at most a few times. On the other hand, a model that can be run quickly, inevitably gets more carefully scrutinized.  Such additional scrutiny makes it practical to see how changes in the model impact results.






2. Relative Weights allows you to use as many variables as you want

The exponential growth in the time needed to run Shapley regression places a constraint on the number of predictor variables that can be included in a model. While the limit on the number of variables will vary based on your patience and computing resources, eventually adding more variables inevitably becomes unfeasible. The negligible computation time of Relative Importance Analysis for all model sizes that a researcher might sensibly consider, avoids the necessity of limiting the model size due to computational constraints.






3. Estimating significance without bootstrapping

You obtain the statistical significance of Shapley regression scores by running the method on bootstrapped data. This increases the time needed many times over, than when running a single model.  In the case of Shapley, an already slow method becomes even slower. Relative Weights is also amenable to bootstrapping, which will not be as computationally expensive as it is for Shapley. However, with Relative Weights, significance can be estimated without bootstrapping because an expression for their standard errors can be developed. Standard errors allow us to test whether the scores are significantly different from zero, which is a way of determining if predictor variables are contributing to the model.






4. Computing importance for other types of regression models

The derivation of Shapley regression relies on R2, which indicates the proportion of variance in the outcome variable explained by the model. Other types of generalized linear models (GLMs), such as logistic and Poisson regression, have no equivalent to R2. While you can jerry-rig pseudo-R statistics, an even bigger problem looms.  Most GLMs take much, much, longer to compute than linear regression.  This means that the time taken increases, reducing the possible number of variables to include.






Computing Relative Weights in R

The flipRegression package on GitHub contains an R function called Regression. This function refers to Relative Weights as Relative Importance to distinguish it from sampling weights (also supported by the package).  Referring to two different things as “weights” could otherwise result in confusion! The following code estimates the Relative Weights for a linear regression model.




library(flipRegression)
glm <- Regression(Q3 ~ Q4A + Q4B + Q4C + Q4D + Q4E + Q4F + Q4G + Q4H + Q4I,
output = "Relative Importance Analysis")






The code below estimates the Relative Weights using an ordered logit model with sampling weights:




library(flipRegression)
glm <- Regression(Q3 ~ Q4A + Q4B + Q4C + Q4D + Q4E + Q4F + Q4G + Q4H + Q4I,
weights = wgt, type = "Ordered Logit", output = "Relative Importance Analysis")



A Displayr document contains the relevant code from this example. There you can explore it in a point-and-click environment. Click here to go to the setup screen for Displayr, after which you will be taken to the document containing the example described in this blog post. You can also upload different data sets if you wish. Additionally, you can access and manipulate the underlying R code if you like –  click on the output of the analysis, and select Properties > R CODE.






Acknowledgements

The outputs shown above use formattable.



Author: Justin Yap

Justin is part of the Data Science team at Displayr. He studied physics, maths and econometrics and has a PhD from the University of New South Wales.

References   [ + ]

1. Lipovetsky, S. and Conklin, M. (2001). Analysis of regression in game theory approach. Appl. Stochastic Models Bus. Ind., 17: 319–330.
2. Lindeman, R.H., Merenda, P.F. and Gold, R.Z. (1980). Introduction to Bivariate and Multivariate Analysis, Scott, Foresman, Glenview IL.
3. Budescu, D.V. (1993). Dominance analysis: a new approach to the problem of relative importance in multiple regression. Psychol Bull 114:542-551.
4. Johnson, J.W. (2000). A heuristic method for estimating the relative weight of predictor variables in multiple regression. Multivariate behavioral research 35, 1-19.
5. LeBreton, J.M., Ployhart, R.E. and Ladd, R.T. (2004). A Monte Carlo Comparison of Relative Importance Methodologies. Organizational Research Methods 7, 258 – 282.
6. Grömping, U. (2015). Variable importance in regression models, WIREs Comput Stat 7, 137-152.
7. Thomas, D.R., Zumbo B.D., Kwan E., Schweitzer L. (2014). On Johnson’s (2000) Relative Weights Method for Assessing Variable Importance: A Reanalysis. Multivariate behavioral research 49, 329-338.

Share
Twitter
Facebook
LinkedIn
GOOGLE
https://www.displayr.com/reasons-to-use-relative-weights/">
RSS
Follow by Email
follow us in feedly
Recent Posts

Try this example out yourself

You can try explore the example used in this blog post yourself in Displayr.

EXPLORE THIS EXAMPLE



4 Comments. Share your thoughts.

  1. Tony Corke

    Thanks Justin – this is an interesting piece on an important topic.

    Is the Relative Weights method different from PMVD (Proportional Marginal Variance Decomposition), which I know has also been proposed as an alternative to Shapley/LMG regression?

    If so, do you have a view on its suitability?

    Thanks,

    Tony


    • Justin Yap

      Hi Tony, PMVD is more similar to Shapley than Relative Weights. Like Shapley, it is expensive to compute when there are many predictor variables. The paper by Grömping that is referred to in the blog provides a good comparison of PMVD against other methods.


  2. Michael Conklin – EVP Marketing & Data Science — GfK

    Hi Justin:

    All your reasons come down to the expensive computational burden of a large number of variables…SV can be slow, SV takes a long time with many variables, Relative Weights allows an easy calculation of significance ( I don’t really know what the significance of importance is….all these methods calculate importance for a given regression model, so significance really is about whether the variable should be in the model or not), Computing importance for other types of models e.g. GLM. Internally at GfK we have solved that issue as well as the speed issue, but that doesn’t mean that Relative Weights is not a perfectly good measure (we also use RW).

    However, I think you miss the big question….why are we (in the Market Research Industry) trying to get a measure of relative importance for a model with 30 or 50 or 100 predictors? By doing so we completely avoid the question of whether our questions are useful in exploring the topic. If you just need to plot relative importance vs performance then any of these techniques will do the job. But, I think a much better use of time would be to understand which few questions we can ask to get an equivalent understanding of the “drivers” of an end result. I think the hope that we will get consistent results from a model with 30 or 40 predictors across waves of a typical MR study is pretty hopeless.

    Nice blog though 🙂


  3. Justin Yap

    Hi Michael,

    Thanks for reading my blog post and apologies for the late reply. I’m amazed and delighted to see the pioneer of Shapley regression in the market research industry comment on my blog post!

    We compute significance as a way of determining if a variable adds any value to the model. A variable that has a low importance but is still significant might still be useful.

    I agree that it makes sense to limit the number of predictors by actually questioning which ones should be there, rather than simply depending upon an algorithm. However if Shapley regression ran faster it could be used as part of this process of eliminating variables when there are many predictors.

    I’m curious to know how speed and computing importance for other types of models has been solved for Shapley regression, is there a public document/paper on this? 🙂

    Cheers,
    Justin
